Tilting Disc Check Valve with Hydraulic Damper – Class 150
ASME B16.34 tilting-disc check valve fitted with a counter-weight lever and a hydraulic damper cylinder. The damper controls the closing stroke to limit flow reversal and water hammer in pump discharge lines, and needs no external power.
- Pressure
- Class 150
- Size Range
- 2" to 24"
- Testing
- API 598
⚠ Pending engineering review: Pending engineering sign-off: pressure figure is a hydro-test (shell) value, not a confirmed Class rating; ductile-iron body option under ASME B16.34 (a steel P-T standard) needs confirmation.
- 01
Pressure Rating
Class 150 (15 Kg/cm²)
- 02
Size Range
- 03
Material
- 04
Standards
01
Pressure Rating
Class 150 (15 Kg/cm²)
Reference standard & materials
Same data as the printed catalogue
Reference standard
- MFG. STD
- ASME B16.34
- Face to Face
- EN 558 SER.-14
- Flange End
- ASME B16.5
- Insp. & Test.
- API 598
- Press & Temp.
- ASME B16.34
Material of construction
| No. | Description | Carbon Steel | Alloy Steel | Ductile Iron |
|---|---|---|---|---|
| 01 | Body | ASTM A216 GR.WCB | ASTM A217 GR.WC9 | ASTM A 536 Gr. 60-40-18 |
| 02 | Disc | ASTM A351 GR.CF8 | ASTM A351 GR.CF8 | ASTM A351 GR.CF8 |
| 03 | Stem | SS 304 | SS 304 | SS 304 |
| 04 | Stem Cover | ASTM A216 GR.WCB | ASTM A217 GR.WC9 | ASTM A 536 Gr. 60-40-18 |
| 05 | Seat | Metal Seat / Soft Seat (EPDM) | Metal Seat / Soft Seat (EPDM) | Soft Seat (EPDM) |
Dimensions
mm · ASME B16.5 flange details · weights on request
| Flange Details, ASME B16.5 | Hydro Test | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Size | DN | A (FE) | OD | PCD | RFD | T | ØH | N | Shell | Seat |
| 2" | 50 | 150 | 152 | 120.6 | 92.1 | 14.3 | 19 | 04 | 15 Kg/cm² | 10 Kg/cm² |
| 2.5" | 65 | 170 | 178 | 139.7 | 104.8 | 15.7 | 19 | 04 | 15 Kg/cm² | 10 Kg/cm² |
| 3" | 80 | 180 | 190 | 152.4 | 127.0 | 17.5 | 19 | 04 | 15 Kg/cm² | 10 Kg/cm² |
| 4" | 100 | 190 | 229 | 190.5 | 157.2 | 22.4 | 19 | 08 | 15 Kg/cm² | 10 Kg/cm² |
| 5" | 125 | — | — | — | — | — | — | — | 15 Kg/cm² | 10 Kg/cm² |
| 6" | 150 | 210 | 279 | 241.3 | 215.9 | 23.9 | 22 | 08 | 15 Kg/cm² | 10 Kg/cm² |
| 8" | 200 | 230 | 343 | 298.4 | 269.9 | 26.9 | 22 | 08 | 15 Kg/cm² | 10 Kg/cm² |
| 10" | 250 | 250 | 406 | 362.0 | 323.8 | 28.4 | 25 | 12 | 15 Kg/cm² | 10 Kg/cm² |
| 12" | 300 | 270 | 483 | 431.8 | 381.0 | 30.2 | 25 | 12 | 15 Kg/cm² | 10 Kg/cm² |
| 14" | 350 | 290 | 533 | 476.2 | 412.8 | 33.3 | 29 | 12 | 15 Kg/cm² | 10 Kg/cm² |
| 16" | 400 | 310 | 597 | 539.8 | 469.9 | 35.1 | 29 | 16 | 15 Kg/cm² | 10 Kg/cm² |
| 18" | 450 | 330 | 635 | 577.8 | 533.4 | 38.1 | 32 | 16 | 15 Kg/cm² | 10 Kg/cm² |
| 20" | 500 | 350 | 698 | 635.0 | 584.2 | 41.1 | 32 | 20 | 15 Kg/cm² | 10 Kg/cm² |
| 24" | 600 | 390 | 813 | 749.3 | 692.2 | 46.0 | 35 | 20 | 15 Kg/cm² | 10 Kg/cm² |
Technical specifications
- Material
- Body: ASTM A216 GR.WCB (CS) / ASTM A217 GR.WC9 (Alloy) / ASTM A536 Gr.60-40-18 (Ductile Iron)
- Pressure Rating
- Class 150 (15 Kg/cm²)
- Temperature Range
- -10°C to +120°C (EPDM seat limited; CS/Ductile Iron body)
- Eng Note
- Pending engineering sign-off: pressure figure is a hydro-test (shell) value, not a confirmed Class rating; ductile-iron body option under ASME B16.34 (a steel P-T standard) needs confirmation.
- Size Range
- 2" to 24" (DN 50–600)
- Disc
- ASTM A351 GR.CF8
- Stem Cover
- ASTM A216 GR.WCB / ASTM A536 Gr.60-40-18 (Ductile Iron)
- Seat
- EPDM / EBONITE RUBBER
- Stem
- SS 304
- End Connections
- Flanged (ASME B16.5)
- Face T To Face
- EN 558 Series 14
- Model Numbers
- VX-TDCV-1303 (Cl.150) with damper
Standards & testing
- MFG. STD: ASME B16.34
- Face to Face: EN 558 SER.-14
- Flange End: ASME B16.5
- Insp. & Test: API 598
- Press. & Temp: ASME B16.34
Custom engineering
Special trims, exotic materials and non-standard dimensions are available against your datasheet — send it with your quote request and our engineering team will respond with a compliant proposal.
